GT1544V Turbocharger 753420-5006S Turbo Charger

Product Name:

GT1544V Turbocharger 753420-5006S Turbo Charger

Product Attribute:

Engine Model:D4164T

Turbo Model:GT1544V

Engine Power:109/ 110kw

Size:OEMcm

G.W:6kg

Turbine Material:K18

Power:109/110kw

Displacement:OEMl

Name:GT1544V Turbocharger 753420-5006S Turbo Charger

TAG:GT1544V

Cooled Type:Oil cooled

Build/Year:2003-2009

Capacity:1560-1600 ccm

Fuel Type:Diesel

Brand:Tanboress

Warranty:12 Months

Certificate:CE/BV/GMC/TUV/ISO9001

Application:

BMW Mini Cooper D (2006) Citroen Berlingo 1.6 HDi FAP (2005) Citroen C 2 1.6 HDi FAP (2005) Citroen C 4 1.6 HDi (2004) Citroen C 5 I 1.6 HDi FAP (2003) Citroen C 5 II 1.6 HDi FAP (2005) Citroen Picasso 1.6 HDi FAP (2004) Citroen Xsara 1.6 HDi FAP (2003) Ford C-MAX 1.6 TDCi (2004) Ford Focus II 1.6 TDCi (2004) Ford Mondeo III 1.6 TDCi (2004-2007) Mazda 3 1.6 DI (2003) Peugeot 1007 1.6 HDi FAP (2005) Peugeot 206 1.6 HDi (2004) Peugeot 207 1.6 HDi (2004) Peugeot 3008 1.6 HDi FAP (2009) Peugeot 307 1.6 HDi (2004) Peugeot 308 1.6 HDi FAP (2007) Peugeot 407 1.6 HDI (2004) Peugeot 5008 1.6 HDi FAP 110 (2009) Peugeot Partner 1.6 HDi FAP (2005) Volvo-PKW C30 1.6D (2006) Volvo-PKW S40 II 1.6D (2004) Volvo-PKW V50 1.6D (2004)

Product Description:

GT1544V Turbocharger 753420-5006S Turbo Charger

Material Description

1.     Compressor Housing : ZL 101 Cast aluminum
2.     Turbine Housing : D-5S. Scope of heat-resistant950°
3.     Bearing Housing : HT250 Gray iron
4.     Compressor Wheel : ZL201 or C355 cast aluminums
5.     Turbine Wheel : K18. Scope of heat-resistant950°
6.     Turbine Shaft : 42CrMo
7.     Floating Bearing : CW713R
8.     Seal Ring : CrMoNiTi
9.     Thrust Bearing : CW713R or ZQSn10-10

Really close to OEM manufacturers quality!

Really the lowest repair rate under the same shelf life!
Really high-temperature resistant, non-deformation for a long time!
Manufacturerprovide you with detailed product material testing report.

Machining Precision Description

High-precision processing equipmentHARDINGE CNC
4-axis linkage machining centerJirfine Taiwan CNC

1.     Compressor Housing: Machining precision up to IT6 grades
2.     Turbine Housing: Machining precision up to IT6 grades
3.     Center Housing: Machining precision up to IT6 grades
4.     Compressor Wheel: Accurate run-out, verticality and ovality
5.       Turbine Wheel: Overall friction welding technology

The more accurate data belong to our trade secrets.
Should further information be required, please feel free to contact us!

Product Performance Testing Description:

1.   The TURBO ROTOR SHAFT & WHEEL Balancing Test(Italy REDAT)
Detection Accuracy = 0.0001g
Test Frequency = 100%
2.   The TURBO CARTRIDGE Balancing Test(UK TECHNICS)
Vibration Detection Accuracy ± 1%
Inspection Frequency = 100%
3.   Bypass Valve Test(Italy REDAT)
Detection Accuracy Test ± 0.5%
Detection Frequency = 100%
4.      Overall Performance Test Bench(Test Bench China NJ408)

Now, Contact us for more professional service and accurate data of our products.

Business Information
Trade Terms: FOB,CIF,EXW
Payment Terms: T/T, Western Union, Paypal, Escrow.
Payment Condition: 30% desposit in advance, 70% balance before delivery
Delivery Time: Within 7 days after the payment
Packing: 1.Neutral Packing Or the package as requirement.
2.One turbo in a Carton.
3.Wooden case is a good choice for ocean shipping.
Shipping: By sea,by air and by express delivery.
After-sale Service:24 Hours around the clock & 12 Months Warranty.

TAG : GT1544V
