Electric Turbocharger GTA1749V Turbo For Ford-Volvo 728768-0004

Product Name:

Electric Turbocharger GTA1749V Turbo For Ford-Volvo 728768-0004

Product Attribute:

Engine Model:DW10BTED

Turbo Model:GTA1749V

Engine Power:136kw

Size:22*24*26cm

G.W:9kg

Turbine Material:K18

Power:136kw,136HP

Name:Electric Turbocharger GTA1749V Turbo For Ford-Volvo 728768-0004

Item name:728768-0004

Cooled Type:Oil cooled

Build/Year:2004-2008

Capacity:1997ccm 2000ccm

Fuel Type:Diesel

Brand:Tanboress

Warranty:12 Months

Certificate:CE/BV/GMC/TUV/ISO9001

Net Weight:8kg

Application:

Ford C-MAX 2.0 TDCi Ford Focus II 2.0 TDCi Ford Kuga 2.0 TDCi Ford Galaxy II 2.0 TDCi Ford Mondeo III 2.0 TDCi Ford S-MAX 2.0 TDCi Volvo-PKW C30 2.0 D Volvo-PKW C70 II 2.0 D Volvo-PKW S40 II 2.0 D Volvo-PKW V40 2.0 D Volvo-PKW V50 2.0 D

Product Description:

Electric Turbocharger GTA1749V Turbo For Ford-Volvo 728768-0004

Material Description
1.     Compressor Housing : ZL 101 Cast aluminum
2.     Turbine Housing : D-5S. Scope of heat-resistant950°
3.     Bearing Housing : HT250 Gray iron
4.     Compressor Wheel : ZL201 or C355 cast aluminums
5.     Turbine Wheel : K18. Scope of heat-resistant950°
6.     Turbine Shaft : 42CrMo
7.     Floating Bearing : CW713R
8.     Seal Ring : CrMoNiTi
9.     Thrust Bearing : CW713R or ZQSn10-10


Really close to OEM manufacturers quality!
    Really the lowest repair rate under the same shelf life!
  Really high-temperature resistant, non-deformation for a long time!
Manufacturerprovide you with detailed product material testing report.

Machining Precision Description


High-precision processing equipmentHARDINGE CNC
4-axis linkage machining centerJirfine Taiwan CNC

1.     Compressor Housing: Machining precision up to IT6 grades
2.     Turbine Housing: Machining precision up to IT6 grades
3.     Center Housing: Machining precision up to IT6 grades
4.     Compressor Wheel: Accurate run-out, verticality and ovality
5.       Turbine Wheel: Overall friction welding technology


The more accurate data belong to our trade secrets.
Should further information be required, please feel free to contact us!

Product Performance Testing Description:

1.   The TURBO ROTOR SHAFT & WHEEL Balancing Test(Italy REDAT)
Detection Accuracy = 0.0001g
Test Frequency = 100%
2.   The TURBO CARTRIDGE Balancing Test(UK TECHNICS)
Vibration Detection Accuracy ± 1%
Inspection Frequency = 100%
3.   Bypass Valve Test(Italy REDAT)
Detection Accuracy Test ± 0.5%
Detection Frequency = 100%
4.      Overall Performance Test Bench(Test Bench China NJ408)


Now, Contact us for more
professional service and accurate data of our products.

Business Information
Trade Terms: FOB,CIF,EXW
Payment Terms: T/T, Western Union, Paypal, Escrow.
Payment Condition: 30% desposit in advance, 70% balance before delivery
Delivery Time: Within 7 days after the payment
Packing: 1.Neutral Packing Or the package as requirement.
2.One turbo in a Carton.
3.Wooden case is a good choice for ocean shipping.
Shipping: By sea,by air and by express delivery.
After-sale Service:24 Hours around the clock & 12 Months Warranty.
