Electric Turbocharger K03 Turbo Charger For K03 Seat 53039880133

Electric Turbocharger K03 Turbo Charger For K03 Seat 53039880133
Electric Turbocharger K03 Turbo Charger For K03 Seat 53039880133
Previous
Next
OEM No/Model:

53039880133

Minimum Order:

1Piece/Pieces

Export Ratio:

91% - 100%

Quality Certificate:

CE

Samples:

Charge

Place of Region:

China

Payment Terms:

L/C,T/T,paypal

Price Terms:

EXW

Delivery Port:

Dalian,Qingdao,Others

Delivery Time:

Within 7 Days After The Payment

Market Type:

After Market

Packing:

1.Neutral Packing Or The Package As Requirement. 2.One Turbo In A Carton. 3.Wooden Case Is A Good Choice For Ocean Shipping.

Current Export Market:

North America,South America,Western Europe,Eastern Europe,Eastern Asia,Southeast Asia,Mid East,Africa,Oceania

Product Details

Product Name:

Electric Turbocharger K03 Turbo Charger For K03 Seat 53039880133

Product Attribute:

Engine Model:CAGA CAGB CAGC

Turbo Model:K03

Engine Power:143kw

Size:OEMcm

G.W:OEMkg

Turbine Material:K18

Power:143kw

Displacement:OEMl

Name:Electric Turbocharger K03 Turbo Charger For K03 Seat 53039880133

Item name:53039880133

Cooled Type:Oil cooled

Build/Year:2007-2013

Capacity:1968ccm

Fuel Type:Diesel

Brand:Tanboress

Warranty:12 Months

Certificate:CE/BV/GMC/TUV/ISO9001

Application:

Audi A4 2.0 TDI (B8) Audi A5 2.0 TDI Audi A6 2.0 TDI (C6) Audi Q5 2.0 TDI Seat Exeo 2.0 TDI

Product Description:

Electric Turbocharger K03 Turbo Charger For K03 Seat 53039880133


TBS No.
TBS-2470 Related Part No. Application For
OEM No. 53039880190 53039880190
53039700190
53039880140
53039700140
53039880133
BV43-140
BV43-133
BV43B-133
03L145702M
03L145702D
03L145702H
03L145701D
Audi A4 2.0 TDI (B8)
Audi A5 2.0 TDI
Audi A6 2.0 TDI (C6)
Audi Q5 2.0 TDI
Seat Exeo 2.0 TDI
Turbo Model K03
Engine Code CAGA CAGB CAGC
Cooled Type Oil cooled
Power 143HP
Build/Year 2007-2013
Capacity 1968ccm
Fuel Type Diesel
Net Weight
Gross Weight
Volume
Brand Tanboress
Warranty 12 Months
Certificate CE/BV/GMC/TUV/ISO9001
Material Description

1.     Compressor Housing : ZL 101 Cast aluminum
2.     Turbine Housing : D-5S. Scope of heat-resistant950°
3.     Bearing Housing : HT250 Gray iron
4.     Compressor Wheel : ZL201 or C355 cast aluminums
5.     Turbine Wheel : K18. Scope of heat-resistant950°
6.     Turbine Shaft : 42CrMo
7.     Floating Bearing : CW713R
8.     Seal Ring : CrMoNiTi
9.     Thrust Bearing : CW713R or ZQSn10-10

Really close to OEM manufacturers quality!

Really the lowest repair rate under the same shelf life!
Really high-temperature resistant, non-deformation for a long time!
Manufacturerprovide you with detailed product material testing report.


Machining Precision Description

High-precision processing equipmentHARDINGE CNC
4-axis linkage machining centerJirfine Taiwan CNC

1.     Compressor Housing: Machining precision up to IT6 grades
2.     Turbine Housing: Machining precision up to IT6 grades
3.     Center Housing: Machining precision up to IT6 grades
4.     Compressor Wheel: Accurate run-out, verticality and ovality
5.       Turbine Wheel: Overall friction welding technology

The more accurate data belong to our trade secrets.
Should further information be required, please feel free to contact us!

Product Performance Testing Description:

1.   The TURBO ROTOR SHAFT & WHEEL Balancing Test(Italy REDAT)
Detection Accuracy = 0.0001g
Test Frequency = 100%
2.   The TURBO CARTRIDGE Balancing Test(UK TECHNICS)
Vibration Detection Accuracy ± 1%
Inspection Frequency = 100%
3.   Bypass Valve Test(Italy REDAT)
Detection Accuracy Test ± 0.5%
Detection Frequency = 100%
4.      Overall Performance Test Bench(Test Bench China NJ408)

Now, Contact us for more
professional service and accurate data of our products.

Business Information
Trade Terms: FOB,CIF,EXW
Payment Terms: T/T, Western Union, Paypal, Escrow.
Payment Condition: 30% desposit in advance, 70% balance before delivery
Delivery Time: Within 7 days after the payment
Packing: 1.Neutral Packing Or the package as requirement.
2.One turbo in a Carton.
3.Wooden case is a good choice for ocean shipping.
Shipping: By sea,by air and by express delivery.
After-sale Service:24 Hours around the clock & 12 Months Warranty.
