Turbocharger BV39 Turbo Charger For Audi Seat Skoda Volkswagen 038253014G

Product Name:

Turbocharger BV39 Turbo Charger For Audi Seat Skoda Volkswagen 038253014G

Product Attribute:

Engine Model:BJB BKC BXE

Turbo Model:BV39

Engine Power:90/ 105kw

Size:OEMcm

G.W:10kg

Turbine Material:K18

Power:90/ 105kw

Displacement:OEMl

Name:Turbocharger BV39 Turbo Charger For Audi 038253014G

Item name:038253014G

Cooled Type:Oil cooled

Build/Year:2002-2009

Capacity:1896 ccm

Fuel Type:Diesel

Brand:Tanboress

Warranty:12 Months

Certificate:CE/BV/GMC/TUV/ISO9001

Net Weight:8kg

Application:

Audi A3 1.9 TDI 8P (PA Seat Altea 1.9 TDI Seat Leon 1.9 TDI Seat Toledo III 1.9 TDI Skoda Octavia II 1.9 TDI Skoda Superb II 1.9 TDI Volkswagen Caddy III 1.9 TDI Volkswagen Golf V 1.9 TDI Volkswagen Jetta V 1.9 TDI Volkswagen Passat B6 1.9 TDI Volkswagen Touran 1.9 TDI)

Product Description:

Turbocharger BV39 Turbo Charger For Audi Seat Skoda Volkswagen 038253014G

1.     Compressor Housing : ZL 101 Cast aluminum
2.     Turbine Housing : D-5S. Scope of heat-resistant950°
3.     Bearing Housing : HT250 Gray iron
4.     Compressor Wheel : ZL201 or C355 cast aluminums
5.     Turbine Wheel : K18. Scope of heat-resistant950°
6.     Turbine Shaft : 42CrMo
7.     Floating Bearing : CW713R
8.     Seal Ring : CrMoNiTi
9.     Thrust Bearing : CW713R or ZQSn10-10

Really close to OEM manufacturers quality!

Really the lowest repair rate under the same shelf life!
Really high-temperature resistant, non-deformation for a long time!
Manufacturerprovide you with detailed product material testing report.

Machining Precision Description

High-precision processing equipmentHARDINGE CNC
4-axis linkage machining centerJirfine Taiwan CNC

1.     Compressor Housing: Machining precision up to IT6 grades
2.     Turbine Housing: Machining precision up to IT6 grades
3.     Center Housing: Machining precision up to IT6 grades
4.     Compressor Wheel: Accurate run-out, verticality and ovality
5.       Turbine Wheel: Overall friction welding technology

The more accurate data belong to our trade secrets.
Should further information be required, please feel free to contact us!

Product Performance Testing Description:

1.   The TURBO ROTOR SHAFT & WHEEL Balancing Test(Italy REDAT)
Detection Accuracy = 0.0001g
Test Frequency = 100%
2.   The TURBO CARTRIDGE Balancing Test(UK TECHNICS)
Vibration Detection Accuracy ± 1%
Inspection Frequency = 100%
3.   Bypass Valve Test(Italy REDAT)
Detection Accuracy Test ± 0.5%
Detection Frequency = 100%
4.      Overall Performance Test Bench(Test Bench China NJ408)

Now, Contact us for more
professional service and accurate data of our products.

Business Information
Trade Terms: FOB,CIF,EXW
Payment Terms: T/T, Western Union, Paypal, Escrow.
Payment Condition: 30% desposit in advance, 70% balance before delivery
Delivery Time: Within 7 days after the payment
Packing: 1.Neutral Packing Or the package as requirement.
2.One turbo in a Carton.
3.Wooden case is a good choice for ocean shipping.
Shipping: By sea,by air and by express delivery.
After-sale Service:24 Hours around the clock & 12 Months Warranty.
