Product Name:
Turbocharger TD04-09B Turbo Charger For Mitsubishi 49177-07501
Product Attribute:
Engine Model:4D56
Turbo Model:TD04-09B
Engine Power:75 84 87kw
Size:OEMcm
G.W:6kg
Turbine Material:K18
Power:75 84 87kw
Displacement:OEMl
Name:Turbocharger TD04-09B Turbo Charger For Mitsubishi 49177-07501
Item name:49177-07501
Cooled Type:Oil cooled
Build/Year:1984-1996
Capacity:1795 ccm 2347 ccm 2477 ccm
Fuel Type:Diesel
Brand:Tanboress
Warranty:12 Months
Certificate:CE/BV/GMC/TUV/ISO9001
Net Weight:5kg
Application:
Mitsubishi Pajero I 2.5 TD Mitsubishi Pajero I 2.3 TD Mitsubishi Pajero II 2.5 TD Mitsubishi L 200 2.5L TD 4WD Mitsubishi L 300 2, 5 TD 4WD (P25W, P25V) Mitsubishi Galant III 1.8 Turbo-D
Product Description:
Turbocharger TD04-09B Turbo Charger For Mitsubishi 49177-07501
TBS No. |
TBS-0013 |
Related Part No. |
Application For |
|
OEM No. |
49177-01500 |
49177-01500
49177-01501
49177-01510
49177-01511
MD094740
MD168053
MD108153
MR335220
MD106720
49177-01010
MD083538
MD168054
49177-01100
MD084231
49177-91100
49177-00640
49177-00710
49177-01000
49177-01020
49177-01030
49177-01200
49177-01210
49177-01220
49177-01230
49177-07500
49177-07501 |
Mitsubishi Pajero I 2.5 TD
Mitsubishi Pajero I 2.3 TD
Mitsubishi Pajero II 2.5 TD
Mitsubishi L 200 2.5L TD 4WD
Mitsubishi L 300 2,5 TD 4WD (P25W,P25V)
Mitsubishi Galant III 1.8 Turbo-D |
|
Turbo Model |
TD04-09B |
|
Engine Code |
4D56 |
|
Cooled Type |
Oil cooled |
|
Power |
75HP 84HP 87HP |
|
Build/Year |
1984-1996 |
|
Capacity |
1795 ccm 2347 ccm 2477 ccm |
|
Fuel Type |
Diesel |
|
Net Weight |
5kg |
|
Gross Weight |
6kg |
|
Volume |
|
|
Brand |
Tanboress |
|
Warranty |
12 Months |
|
Certificate |
CE/BV/GMC/TUV/ISO9001 |
Material Description
1. Compressor Housing : ZL 101 Cast aluminum
2. Turbine Housing : D-5S. Scope of heat-resistant950°
3. Bearing Housing : HT250 Gray iron
4. Compressor Wheel : ZL201 or C355 cast aluminums
5. Turbine Wheel : K18. Scope of heat-resistant950°
6. Turbine Shaft : 42CrMo
7. Floating Bearing : CW713R
8. Seal Ring : CrMoNiTi
9. Thrust Bearing : CW713R or ZQSn10-10
Really close to OEM manufacturers quality!
Really the lowest repair rate under the same shelf life!
Really high-temperature resistant, non-deformation for a long time!
Manufacturerprovide you with detailed product material testing report.
Machining Precision Description
High-precision processing equipmentHARDINGE CNC
4-axis linkage machining centerJirfine Taiwan CNC
1. Compressor Housing: Machining precision up to IT6 grades
2. Turbine Housing: Machining precision up to IT6 grades
3. Center Housing: Machining precision up to IT6 grades
4. Compressor Wheel: Accurate run-out, verticality and ovality
5. Turbine Wheel: Overall friction welding technology
The more accurate data belong to our trade secrets.
Should further information be required, please feel free to contact us!
Product Performance Testing Description:
1. The TURBO ROTOR SHAFT & WHEEL Balancing Test(Italy REDAT)
Detection Accuracy = 0.0001g
Test Frequency = 100%
2. The TURBO CARTRIDGE Balancing Test(UK TECHNICS)
Vibration Detection Accuracy ± 1%
Inspection Frequency = 100%
3. Bypass Valve Test(Italy REDAT)
Detection Accuracy Test ± 0.5%
Detection Frequency = 100%
4. Overall Performance Test Bench(Test Bench China NJ408)
Now, Contact us for more
professional service and accurate data of our products.
Business Information
Trade Terms: FOB,CIF,EXW
Payment Terms: T/T, Western Union, Paypal, Escrow.
Payment Condition: 30% desposit in advance, 70% balance before delivery
Delivery Time: Within 7 days after the payment
Packing: 1.Neutral Packing Or the package as requirement.
2.One turbo in a Carton.
3.Wooden case is a good choice for ocean shipping.
Shipping: By sea,by air and by express delivery.
After-sale Service:24 Hours around the clock & 12 Months Warranty.
