Product Name:
Turbocharger GT1749V (S1) Turbo Charger For BMW 7787626G
Product Attribute:
Engine Model:M47TU
Turbo Model:GT1749V (S1)
Engine Power:150kw
Size:OEMcm
G.W:7.5kg
Turbine Material:K18
Power:150kw
Displacement:OEMl
Name:Turbocharger GT1749V (S1) Turbo Charger For BMW 7787626G
TAG:7787626G
Cooled Type:Oil cooled
Fuel Type:Diesel
Brand:Tanboress
Warranty:12 Months
Certificate:CE/BV/GMC/TUV/ISO9001
Net Weight:6kg
Capacity:1995ccm
Build/Year:2001
Application:
BMW X3 2.0 d (E83 ( E83N) BMW 320 d ( E46))
Product Description:
Turbocharger GT1749V (S1) Turbo Charger For BMW 7787626G
TBS No. |
TBS-0123 |
Related Part No. |
|
OEM No. |
750431-5013S |
750431-5013S
750431-5012S
750431-9012S
750431-5009S
750431-0009
717478-6/5
717478-4/3
717478-2/1
11657794144
EU3
750431-0012
7794140D
7787626F
7787628G
7787627G
7787626G
717478-0001
717478-0004
717478-0005
717478-0006
750431-0002
750431-0003
750431-0006
7794144D |
7794144SD
11657787626F
11657787626G
11657787628G
11657794144D
11657794144SD
7794144
77876260
116577876260
7787627F
7787626H
7787627H
7787628H
77876261
116577876261
7794144E03
11657787627G
77876271
116577876271
7794140E03
11657794140E03
11657794140D
7794140C |
|
Turbo Model |
GT1749V (S1) |
|
Engine Code |
M47TU |
|
Cooled Type |
Oil cooled |
|
Power |
150HP |
|
Build/Year |
2001 |
|
Capacity |
1995ccm |
|
Fuel Type |
Diesel |
|
Net Weight |
6KG |
|
Gross Weight |
7.5KG |
|
Application |
BMW X3 2.0 d (E83 / E83N)
BMW 320 d ( E46) |
|
Brand |
Tanboress |
|
Warranty |
12 Months |
|
Certificate |
CE/BV/GMC/TUV/ISO9001 |
Material Description
1. Compressor Housing : ZL 101 Cast aluminum
2. Turbine Housing : D-5S. Scope of heat-resistant950°
3. Bearing Housing : HT250 Gray iron
4. Compressor Wheel : ZL201 or C355 cast aluminums
5. Turbine Wheel : K18. Scope of heat-resistant950°
6. Turbine Shaft : 42CrMo
7. Floating Bearing : CW713R
8. Seal Ring : CrMoNiTi
9. Thrust Bearing : CW713R or ZQSn10-10
Really close to OEM manufacturers quality!
Really the lowest repair rate under the same shelf life!
Really high-temperature resistant, non-deformation for a long time!
Manufacturerprovide you with detailed product material testing report.
Machining Precision Description
High-precision processing equipmentHARDINGE CNC
4-axis linkage machining centerJirfine Taiwan CNC
1. Compressor Housing: Machining precision up to IT6 grades
2. Turbine Housing: Machining precision up to IT6 grades
3. Center Housing: Machining precision up to IT6 grades
4. Compressor Wheel: Accurate run-out, verticality and ovality
5. Turbine Wheel: Overall friction welding technology
The more accurate data belong to our trade secrets.
Should further information be required, please feel free to contact us!
Product Performance Testing Description:
1. The TURBO ROTOR SHAFT & WHEEL Balancing Test(Italy REDAT)
Detection Accuracy = 0.0001g
Test Frequency = 100%
2. The TURBO CARTRIDGE Balancing Test(UK TECHNICS)
Vibration Detection Accuracy ± 1%
Inspection Frequency = 100%
3. Bypass Valve Test(Italy REDAT)
Detection Accuracy Test ± 0.5%
Detection Frequency = 100%
4. Overall Performance Test Bench(Test Bench China NJ408)
Now, Contact us for more
professional service and accurate data of our products.
Business Information
Trade Terms: FOB,CIF,EXW
Payment Terms: T/T, Western Union, Paypal, Escrow.
Payment Condition: 30% desposit in advance, 70% balance before delivery
Delivery Time: Within 7 days after the payment
Packing: 1.Neutral Packing Or the package as requirement.
2.One turbo in a Carton.
3.Wooden case is a good choice for ocean shipping.
Shipping: By sea,by air and by express delivery.
After-sale Service:24 Hours around the clock & 12 Months Warranty.
