Product Name:
Turbocharger GT3576D Turbo Charger For Hinoi 479016-0001
Product Attribute:
Engine Model:J08C-TI
Turbo Model:GT3576D
Engine Power:253kw
Size:OEMcm
G.W:15kg
Turbine Material:K18
Power:253kw
Displacement:OEMl
Name:Turbocharger GT3576D Turbo Charger For Hinoi 479016-0001
Item name:479016-0001
Cooled Type:Water cooled
Fuel Type:Diesel
Brand:Tanboress
Warranty:12 Months
Certificate:CE/BV/GMC/TUV/ISO9001
Build/Year:1997
Capacity:8000ccm
Net Weight:14kg
Application:
Hino Truck
Product Description:
Turbocharger GT3576D Turbo Charger For Hinoi 479016-0001
|
TBS No. |
TBS-0320 |
Related Part No. |
Application For |
|
OEM No. |
750849-0001 |
750849-0001
750849-5001S
750849-1
479016-0001
479016-0002
750849-0002
241003251
241003251C
24100-3251C
24100-3251 |
Hino Truck |
|
Turbo Model |
GT3576D |
|
Engine Code |
J08C-TI |
|
Cooled Type |
Water cooled |
|
Power |
253KW |
|
Build/Year |
1997 |
|
Capacity |
8000ccm |
|
Fuel Type |
Diesel |
|
Net Weight |
14kg |
|
Gross Weight |
15kg |
|
Volume |
|
|
Brand |
Tanboress |
|
Warranty |
12 Months |
|
Certificate |
CE/BV/GMC/TUV/ISO9001 |
Material Description
1. Compressor Housing : ZL 101 Cast aluminum
2. Turbine Housing : D-5S. Scope of heat-resistant950°
3. Bearing Housing : HT250 Gray iron
4. Compressor Wheel : ZL201 or C355 cast aluminums
5. Turbine Wheel : K18. Scope of heat-resistant950°
6. Turbine Shaft : 42CrMo
7. Floating Bearing : CW713R
8. Seal Ring : CrMoNiTi
9. Thrust Bearing : CW713R or ZQSn10-10
Really close to OEM manufacturers quality!
Really the lowest repair rate under the same shelf life!
Really high-temperature resistant, non-deformation for a long time!
Manufacturerprovide you with detailed product material testing report.
Machining Precision Description
High-precision processing equipmentHARDINGE CNC
4-axis linkage machining centerJirfine Taiwan CNC
1. Compressor Housing: Machining precision up to IT6 grades
2. Turbine Housing: Machining precision up to IT6 grades
3. Center Housing: Machining precision up to IT6 grades
4. Compressor Wheel: Accurate run-out, verticality and ovality
5. Turbine Wheel: Overall friction welding technology
The more accurate data belong to our trade secrets.
Should further information be required, please feel free to contact us!
Product Performance Testing Description:
1. The TURBO ROTOR SHAFT & WHEEL Balancing Test(Italy REDAT)
Detection Accuracy = 0.0001g
Test Frequency = 100%
2. The TURBO CARTRIDGE Balancing Test(UK TECHNICS)
Vibration Detection Accuracy ± 1%
Inspection Frequency = 100%
3. Bypass Valve Test(Italy REDAT)
Detection Accuracy Test ± 0.5%
Detection Frequency = 100%
4. Overall Performance Test Bench(Test Bench China NJ408)
Now, Contact us for more
professional service and accurate data of our products.
Business Information
Trade Terms: FOB,CIF,EXW
Payment Terms: T/T, Western Union, Paypal, Escrow.
Payment Condition: 30% desposit in advance, 70% balance before delivery
Delivery Time: Within 7 days after the payment
Packing: 1.Neutral Packing Or the package as requirement.
2.One turbo in a Carton.
3.Wooden case is a good choice for ocean shipping.
Shipping: By sea,by air and by express delivery.
After-sale Service:24 Hours around the clock & 12 Months Warranty.
