Turbocharger BHT3B / HT3B Turbo Charger For Cummins 3523272

Turbocharger BHT3B / HT3B Turbo Charger For Cummins 3523272
Turbocharger BHT3B / HT3B Turbo Charger For Cummins 3523272
Previous
Next
OEM No/Model:

3523272

Minimum Order:

1Piece/Pieces

Export Ratio:

91% - 100%

Quality Certificate:

CE

Samples:

Charge

Place of Region:

China

Payment Terms:

L/C,T/T,paypal

Price Terms:

EXW

Delivery Port:

Dalian,Qingdao,Others

Delivery Time:

Within 7 Days After The Payment

Market Type:

After Market

Packing:

1.Neutral Packing Or The Package As Requirement. 2.One Turbo In A Carton. 3.Wooden Case Is A Good Choice For Ocean Shipping.

Current Export Market:

North America,South America,Western Europe,Eastern Europe,Eastern Asia,Southeast Asia,Mid East,Africa,Oceania

Product Details

Product Name:

Turbocharger BHT3B / HT3B Turbo Charger For Cummins 3523272

Product Attribute:

Engine Model:NTCC350/NTC350/NTA855/ 88NT400

Turbo Model:BHT3B / HT3B

Engine Power:261kw

Size:OEMcm

G.W:24kg

Turbine Material:K18

Power:261kw

Displacement:OEMl

Name:Turbocharger BHT3B / HT3B Turbo Charger For Cummins 3523272

Item name:3523272

Cooled Type:Oil cooled

Fuel Type:Diesel

Brand:Tanboress

Warranty:12 Months

Certificate:CE/BV/GMC/TUV/ISO9001

Net Weight:22kg

Build/Year:1986-1994

Capacity:5.7L

Application:

Cummins Truck

Product Description:



Turbocharger BHT3B / HT3B Turbo Charger For Cummins 3523272

TBS No. TBS-0977 Related Part No. Application For
OEM No. 196441 196441
3523273
3801617
3522865
3522866
3801613
3524206
3523272
3521830
3521053
3801613RX
3801476RX
3527547
3527038
167713
3803108
3527046
3527048
3529032
3527047
Cummins Truck
Turbo Model BHT3B / HT3B
Engine Code NTCC350/NTC350/NTA855/ 88NT400
Cooled Type Oil cooled
Power 261KW
Build/Year 1986-1994
Capacity 5.7L
Fuel Type Diesel
Net Weight 22kg
Gross Weight 24kg
Volume
Brand Tanboress
Warranty 12 Months
Certificate CE/BV/GMC/TUV/ISO9001
Material Description

1.     Compressor Housing : ZL 101 Cast aluminum
2.     Turbine Housing : D-5S. Scope of heat-resistant950°
3.     Bearing Housing : HT250 Gray iron
4.     Compressor Wheel : ZL201 or C355 cast aluminums
5.     Turbine Wheel : K18. Scope of heat-resistant950°
6.     Turbine Shaft : 42CrMo
7.     Floating Bearing : CW713R
8.     Seal Ring : CrMoNiTi
9.     Thrust Bearing : CW713R or ZQSn10-10

Really close to OEM manufacturers quality!

Really the lowest repair rate under the same shelf life!
Really high-temperature resistant, non-deformation for a long time!
Manufacturerprovide you with detailed product material testing report.


Machining Precision Description

High-precision processing equipmentHARDINGE CNC
4-axis linkage machining centerJirfine Taiwan CNC

1.     Compressor Housing: Machining precision up to IT6 grades
2.     Turbine Housing: Machining precision up to IT6 grades
3.     Center Housing: Machining precision up to IT6 grades
4.     Compressor Wheel: Accurate run-out, verticality and ovality
5.       Turbine Wheel: Overall friction welding technology

The more accurate data belong to our trade secrets.
Should further information be required, please feel free to contact us!

Product Performance Testing Description:

1.   The TURBO ROTOR SHAFT & WHEEL Balancing Test(Italy REDAT)
Detection Accuracy = 0.0001g
Test Frequency = 100%
2.   The TURBO CARTRIDGE Balancing Test(UK TECHNICS)
Vibration Detection Accuracy ± 1%
Inspection Frequency = 100%
3.   Bypass Valve Test(Italy REDAT)
Detection Accuracy Test ± 0.5%
Detection Frequency = 100%
4.      Overall Performance Test Bench(Test Bench China NJ408)
