K03 Turbo 03L253056A Audi Skoda VW Electric Turbocharger

Product Name:

K03 Turbo 03L253056A Audi Skoda VW Electric Turbocharger

Product Attribute:

Engine Model:CBAB/CBDA/CBDB

Turbo Model:K03

Engine Power:140kw

Turbine Material:K18

Power:140kw

Cooled Type:Oil cooled

Build/Year:2006-2009

Capacity:1968ccm

Fuel Type:Diesel

Brand:Tanboress

Warranty:12 Months

Certificate:CE/BV/GMC/TUV/ISO9001

Application:

Audi A3 2.0 TDI (8P (PA) Skoda Yeti 2.0 TDI Volkswagen Eos 2.0 TDI Volkswagen Golf V 2.0 TDI Volkswagen Golf VI 2.0 TDI Volkswagen Passat B6 2.0 TDI Volkswagen Scirocco 2.0 TDI)

Product Description:

K03 Turbo 03L253056A Audi Skoda VW Electric Turbocharger

Material Description
1.     Compressor Housing : ZL 101 Cast aluminum
2.     Turbine Housing : D-5S. Scope of heat-resistant950°
3.     Bearing Housing : HT250 Gray iron
4.     Compressor Wheel : ZL201 or C355 cast aluminums
5.     Turbine Wheel : K18. Scope of heat-resistant950°
6.     Turbine Shaft : 42CrMo
7.     Floating Bearing : CW713R
8.     Seal Ring : CrMoNiTi
9.     Thrust Bearing : CW713R or ZQSn10-10

Really close to OEM manufacturers quality!
Really the lowest repair rate under the same shelf life!
Really high-temperature resistant, non-deformation for a long time!
Manufacturerprovide you with detailed product material testing report.

Machining Precision Description


High-precision processing equipmentHARDINGE CNC
4-axis linkage machining centerJirfine Taiwan CNC


1.     Compressor Housing: Machining precision up to IT6 grades
2.     Turbine Housing: Machining precision up to IT6 grades
3.     Center Housing: Machining precision up to IT6 grades
4.     Compressor Wheel: Accurate run-out, verticality and ovality
5.       Turbine Wheel: Overall friction welding technology


The more accurate data belong to our trade secrets.
Should further information be required, please feel free to contact us!


Product Performance Testing Description:

1.   The TURBO ROTOR SHAFT & WHEEL Balancing Test(Italy REDAT)
Detection Accuracy = 0.0001g
Test Frequency = 100%
2.   The TURBO CARTRIDGE Balancing Test(UK TECHNICS)
Vibration Detection Accuracy ± 1%
Inspection Frequency = 100%
3.   Bypass Valve Test(Italy REDAT)
Detection Accuracy Test ± 0.5%
Detection Frequency = 100%
4.      Overall Performance Test Bench(Test Bench China NJ408)


Now, Contact us for more professional service and accurate data of our products.


Business Information
Trade Terms: FOB,CIF,EXW
Payment Terms: T/T, Western Union, Paypal, Escrow.
Payment Condition: 30% desposit in advance, 70% balance before delivery
Delivery Time: Within 7 days after the payment
Packing: 1.Neutral Packing Or the package as requirement.
2.One turbo in a Carton.
3.Wooden case is a good choice for ocean shipping.
Shipping: By sea,by air and by express delivery.
After-sale Service:24 Hours around the clock & 12 Months Warranty.
