Product Name:
Turbocharger H2C Turbo Charger ForIveco | Baudouin | Volvo 3518613
Product Attribute:
Engine Model:2LT
Turbo Model:H2C
Engine Power:136kw
Size:OEMcm
G.W:9kg
Turbine Material:K18
Power:136kw
Displacement:OEMl
Name:Turbocharger H2C Turbo Charger ForIveco Baudouin Volvo 3518613
Item name:3518613
Cooled Type:Oil cooled
Build/Year:2004
Capacity:2500 ccm
Fuel Type:Diesel
Brand:Tanboress
Warranty:12 Months
Certificate:CE/BV/GMC/TUV/ISO9001
Net Weight:9kg
Application:
Iveco Marine 8210SRM01 8361SRM10 8281SRM | Baudouin 6F12SRY | Volvo B10B Truck THD100E TD100GA TD101GB TD100G | Volvo N10 Truck THD100E TD100GA TD101GB TD100G | Volvo F10 Truck THD100E TD100GA TD101GB TD100G
Product Description:
Turbocharger H2C Turbo Charger ForIveco | Baudouin | Volvo 3518613
TBS No. |
TBS-0074 |
Related Part No. |
Application For |
OEM No. |
3518613 |
3518613
3518613D
3521810
3523022
3591964
3591971
4033181
4033228
198639
312540
11033130
1460033
14600330Z
1545073
1545074
1545097
1545098
4002205
5002205
5002206
61315684
61315685
61316305
61317004
61318577
6886157
6888157
8103605
846652
8466526
856652 |
Iveco Marine 8210SRM01 8361SRM10 8281SRM | Baudouin 6F12SRY | Volvo B10B Truck THD100E TD100GA TD101GB TD100G | Volvo N10 Truck THD100E TD100GA TD101GB TD100G | Volvo F10 Truck THD100E TD100GA TD101GB TD100G |
Turbo Model |
H2C |
Engine Code |
2KD-FTV |
Cooled Type |
oil cooled |
Power |
136HP |
Build/Year |
2004 |
Capacity |
2500 ccm |
Fuel Type |
Diesel |
Net Weight |
8kg |
Gross Weight |
9kg |
Volume |
|
Brand |
Tanboress |
Warranty |
12 Months |
Certificate |
CE/BV/GMC/TUV/ISO9001 |
Material Description
1. Compressor Housing : ZL 101 Cast aluminum
2. Turbine Housing : D-5S. Scope of heat-resistant950°
3. Bearing Housing : HT250 Gray iron
4. Compressor Wheel : ZL201 or C355 cast aluminums
5. Turbine Wheel : K18. Scope of heat-resistant950°
6. Turbine Shaft : 42CrMo
7. Floating Bearing : CW713R
8. Seal Ring : CrMoNiTi
9. Thrust Bearing : CW713R or ZQSn10-10
Really close to OEM manufacturers quality!
Really the lowest repair rate under the same shelf life!
Really high-temperature resistant, non-deformation for a long time!
Manufacturerprovide you with detailed product material testing report.
Machining Precision Description
High-precision processing equipmentHARDINGE CNC
4-axis linkage machining centerJirfine Taiwan CNC
1. Compressor Housing: Machining precision up to IT6 grades
2. Turbine Housing: Machining precision up to IT6 grades
3. Center Housing: Machining precision up to IT6 grades
4. Compressor Wheel: Accurate run-out, verticality and ovality
5. Turbine Wheel: Overall friction welding technology
The more accurate data belong to our trade secrets.
Should further information be required, please feel free to contact us!
Product Performance Testing Description:
1. The TURBO ROTOR SHAFT & WHEEL Balancing Test(Italy REDAT)
Detection Accuracy = 0.0001g
Test Frequency = 100%
2. The TURBO CARTRIDGE Balancing Test(UK TECHNICS)
Vibration Detection Accuracy ± 1%
Inspection Frequency = 100%
3. Bypass Valve Test(Italy REDAT)
Detection Accuracy Test ± 0.5%
Detection Frequency = 100%
4. Overall Performance Test Bench(Test Bench China NJ408)
Now, Contact us for more
professional service and accurate data of our products.
Business Information
Trade Terms: FOB,CIF,EXW
Payment Terms: T/T, Western Union, Paypal, Escrow.
Payment Condition: 30% desposit in advance, 70% balance before delivery
Delivery Time: Within 7 days after the payment
Packing: 1.Neutral Packing Or the package as requirement.
2.One turbo in a Carton.
3.Wooden case is a good choice for ocean shipping.
Shipping: By sea,by air and by express delivery.
After-sale Service:24 Hours around the clock & 12 Months Warranty.
