Turbocharger BV39 | KP39 Turbo Charger For Audi | Seat 54399700022

Product Name:

Turbocharger BV39 | KP39 Turbo Charger For Audi | Seat 54399700022

Product Attribute:

Engine Model:ALH AHF

Turbo Model:BV39 KP39

Engine Power:136kw

Size:OEMcm

G.W:10kg

Turbine Material:K18

Power:136kw

Displacement:OEMl

Name:Turbocharger BV39 KP39 Turbo Charger For Audi Seat 54399700022

Item name:54399700022

Cooled Type:Oil cooled

Build/Year:2004

Capacity:2500 ccm

Fuel Type:Diesel

Brand:Tanboress

Warranty:12 Months

Certificate:CE/BV/GMC/TUV/ISO9001

Net Weight:10kg

Application:

Audi A3 1.9 TDI 8P (PA 105 HP | Seat Altea 1.9 TDI 105 HP | Seat Leon 1.9 TDI 90 HP | Seat Leon 1.9 TDI 105 HP | Seat Toledo III 1.9 TDI 105 HP | Skoda Octavia II 1.9 TDI 105 HP | Skoda Superb II 1.9 TDI 105 HP | Volkswagen Caddy III 1.9 TDI 90 HP | Volkswagen Caddy III 1.9 TDI 105 HP | Volkswagen Golf V 1.9 TDI 90 HP | Volkswagen Golf V 1.9 TDI 105 HP | Volkswagen Jetta V 1.9 TDI 105 HP | Volkswagen Passat B6 1.9 TDI 105 HP | Volkswagen Touran 1.9 TDI 90 HP | Volkswagen Touran 1.9 TDI 101 HP | Volkswagen Touran 1.9 TDI 105 HP)

Product Description:

Turbocharger BV39 | KP39 Turbo Charger For Audi | Seat 54399700022


Material Description

1.     Compressor Housing : ZL 101 Cast aluminum
2.     Turbine Housing : D-5S. Scope of heat-resistant950°
3.     Bearing Housing : HT250 Gray iron
4.     Compressor Wheel : ZL201 or C355 cast aluminums
5.     Turbine Wheel : K18. Scope of heat-resistant950°
6.     Turbine Shaft : 42CrMo
7.     Floating Bearing : CW713R
8.     Seal Ring : CrMoNiTi
9.     Thrust Bearing : CW713R or ZQSn10-10

Really close to OEM manufacturers quality!

Really the lowest repair rate under the same shelf life!
Really high-temperature resistant, non-deformation for a long time!
Manufacturerprovide you with detailed product material testing report.

Machining Precision Description

High-precision processing equipmentHARDINGE CNC
4-axis linkage machining centerJirfine Taiwan CNC

1.     Compressor Housing: Machining precision up to IT6 grades
2.     Turbine Housing: Machining precision up to IT6 grades
3.     Center Housing: Machining precision up to IT6 grades
4.     Compressor Wheel: Accurate run-out, verticality and ovality
5.       Turbine Wheel: Overall friction welding technology

The more accurate data belong to our trade secrets.
Should further information be required, please feel free to contact us!

Product Performance Testing Description:

1.   The TURBO ROTOR SHAFT & WHEEL Balancing Test(Italy REDAT)
Detection Accuracy = 0.0001g
Test Frequency = 100%
2.   The TURBO CARTRIDGE Balancing Test(UK TECHNICS)
Vibration Detection Accuracy ± 1%
Inspection Frequency = 100%
3.   Bypass Valve Test(Italy REDAT)
Detection Accuracy Test ± 0.5%
Detection Frequency = 100%
4.      Overall Performance Test Bench(Test Bench China NJ408)

Now, Contact us for more
professional service and accurate data of our products.

Business Information
Trade Terms: FOB,CIF,EXW
Payment Terms: T/T, Western Union, Paypal, Escrow.
Payment Condition: 30% desposit in advance, 70% balance before delivery
Delivery Time: Within 7 days after the payment
Packing: 1.Neutral Packing Or the package as requirement.
2.One turbo in a Carton.
3.Wooden case is a good choice for ocean shipping.
Shipping: By sea,by air and by express delivery.
After-sale Service:24 Hours around the clock & 12 Months Warranty.
