Product Name:
Turbocharger KP35 Turbo Charger For Isuzu | Opel VA430015
Product Attribute:
Engine Model:4JX1 4JX1TC
Turbo Model:KP35
Engine Power:RHF5kw
Size:OEMcm
G.W:7kg
Turbine Material:K18
Power:130kw
Displacement:OEMl
Name:Turbocharger KP35 Turbo Charger For Isuzu Opel VA430015
Item name:VA430015
Cooled Type:Oil cooled
Build/Year:2004
Capacity:2460 ccm
Fuel Type:Diesel
Brand:Tanboress
Warranty:12 Months
Certificate:CE/BV/GMC/TUV/ISO9001
Net Weight:7kg
Application:
Isuzu Trooper 3.0 159 HP | Opel Monterey B 3.0 DTI 159 HP
Product Description:
Turbocharger KP35 Turbo Charger For Isuzu | Opel VA430015
TBS No. |
TBS-0042 |
Related Part No. |
Application For |
OEM No.
|
VA430015 |
VICF
VIDS
RHF5VICF
RHF5VIDS
VA430015
VB430015
VC430015
VE430015
VF430015
VG430015
VH430015
VI430015
VJ430015
VK430015
VL430015
VA430070
VB430070
860001
860040
860065
8973125140
8971371093
8971371094
8971371095
8971371097
8971371098
8971371099
8972503640
8972503641
8972503642
897376273
97312514
97137109
97250364
97376273
98102371
8-97137-109-3
8-97137-109-4
8-97137-109-5
8-97137-109-7
8-97137-109-8 |
Isuzu Trooper 3.0 159 HP | Opel Monterey B 3.0 DTI 159 HP |
|
Turbo Model |
RHF5 |
|
Engine Code |
R5K AXD |
|
Cooled Type |
Oil cooled |
|
Power |
130HP |
|
Build/Year |
2004 |
|
Capacity |
2460 ccm |
|
Fuel Type |
Diesel |
|
Net Weight |
6kg |
|
Gross Weight |
7kg |
|
Volume |
|
|
Brand |
Tanboress |
|
Warranty |
12 Months |
|
Certificate |
CE/BV/GMC/TUV/ISO9001 |
Material Description
1. Compressor Housing : ZL 101 Cast aluminum
2. Turbine Housing : D-5S. Scope of heat-resistant950°
3. Bearing Housing : HT250 Gray iron
4. Compressor Wheel : ZL201 or C355 cast aluminums
5. Turbine Wheel : K18. Scope of heat-resistant950°
6. Turbine Shaft : 42CrMo
7. Floating Bearing : CW713R
8. Seal Ring : CrMoNiTi
9. Thrust Bearing : CW713R or ZQSn10-10
Really close to OEM manufacturers quality!
Really the lowest repair rate under the same shelf life!
Really high-temperature resistant, non-deformation for a long time!
Manufacturerprovide you with detailed product material testing report.
Machining Precision Description
High-precision processing equipmentHARDINGE CNC
4-axis linkage machining centerJirfine Taiwan CNC
1. Compressor Housing: Machining precision up to IT6 grades
2. Turbine Housing: Machining precision up to IT6 grades
3. Center Housing: Machining precision up to IT6 grades
4. Compressor Wheel: Accurate run-out, verticality and ovality
5. Turbine Wheel: Overall friction welding technology
The more accurate data belong to our trade secrets.
Should further information be required, please feel free to contact us!
Product Performance Testing Description:
1. The TURBO ROTOR SHAFT & WHEEL Balancing Test(Italy REDAT)
Detection Accuracy = 0.0001g
Test Frequency = 100%
2. The TURBO CARTRIDGE Balancing Test(UK TECHNICS)
Vibration Detection Accuracy ± 1%
Inspection Frequency = 100%
3. Bypass Valve Test(Italy REDAT)
Detection Accuracy Test ± 0.5%
Detection Frequency = 100%
4. Overall Performance Test Bench(Test Bench China NJ408)
Now, Contact us for more
professional service and accurate data of our products.
Business Information
Trade Terms: FOB,CIF,EXW
Payment Terms: T/T, Western Union, Paypal, Escrow.
Payment Condition: 30% desposit in advance, 70% balance before delivery
Delivery Time: Within 7 days after the payment
Packing: 1.Neutral Packing Or the package as requirement.
2.One turbo in a Carton.
3.Wooden case is a good choice for ocean shipping.
Shipping: By sea,by air and by express delivery.
After-sale Service:24 Hours around the clock & 12 Months Warranty.
