Product Name:
Turbocharger S200G Turbo Charger For Deutz | Volvo 56201970001
Product Attribute:
Engine Model:D375A-5
Turbo Model:S200G
Engine Power:130 136 140kw
Size:OEMcm
G.W:8kg
Turbine Material :K18
Power:130 136 140kw
Displacement:OEMl
Name:Turbocharger S200G Turbo Charger CHRA For Deutz Volvo 56201970001
Item name:56201970001
Cooled Type:water cooled
Build/Year:2000-2008
Capacity:1896 ccm/1968 ccm
Fuel Type:Diesel
Brand:Tanboress
Warranty:12 Months
Certificate:CE/BV/GMC/TUV/ISO9001
Net Weight:8kg
Application:
Deutz Industriemotor 268 HP | Volvo L110 L110E L120 L120E 268 HP
Product Description:
Turbocharger S200G Turbo Charger CHRA For Deutz | Volvo 56201970001
TBS No. |
TBS-0451 |
Related Part No. |
Application For |
|
OEM No. |
56201970001 |
56201970001
56209700001
56209880001
5620 197 0001
5620 970 0001
5620 988 0001
5620-197-0001
5620-970-0001
5620-988-0001
318754
318815
3802190
20571676
6005030553
4285322
4285322KZ
04285322
04285322KZ
4259318
4259318KZ
04259318
04259318KZ
S200G-76H24AEFGM0.85DA11
|
Deutz Industriemotor 268 HP | Volvo L110 L110E L120 L120E 268 HP |
|
Turbo Model |
S200G |
|
Engine Code |
1.8 L - 5V longs/along |
|
Cooled Type |
water cooled |
|
Power |
130HP / 136HP/140HP |
|
Build/Year |
2000-2008 |
|
Capacity |
1896 ccm/1968 ccm |
|
Fuel Type |
Diesel |
|
Net Weight |
7kg |
|
Gross Weight |
8kg |
|
Volume |
|
|
Brand |
Tanboress |
|
Warranty |
12 Months |
|
Certificate |
CE/BV/GMC/TUV/ISO9001 |
Material Description
1. Compressor Housing : ZL 101 Cast aluminum
2. Turbine Housing : D-5S. Scope of heat-resistant950°
3. Bearing Housing : HT250 Gray iron
4. Compressor Wheel : ZL201 or C355 cast aluminums
5. Turbine Wheel : K18. Scope of heat-resistant950°
6. Turbine Shaft : 42CrMo
7. Floating Bearing : CW713R
8. Seal Ring : CrMoNiTi
9. Thrust Bearing : CW713R or ZQSn10-10
Really close to OEM manufacturers quality!
Really the lowest repair rate under the same shelf life!
Really high-temperature resistant, non-deformation for a long time!
Manufacturerprovide you with detailed product material testing report.
Machining Precision Description
High-precision processing equipmentHARDINGE CNC
4-axis linkage machining centerJirfine Taiwan CNC
1. Compressor Housing: Machining precision up to IT6 grades
2. Turbine Housing: Machining precision up to IT6 grades
3. Center Housing: Machining precision up to IT6 grades
4. Compressor Wheel: Accurate run-out, verticality and ovality
5. Turbine Wheel: Overall friction welding technology
The more accurate data belong to our trade secrets.
Should further information be required, please feel free to contact us!
Product Performance Testing Description:
1. The TURBO ROTOR SHAFT & WHEEL Balancing Test(Italy REDAT)
Detection Accuracy = 0.0001g
Test Frequency = 100%
2. The TURBO CARTRIDGE Balancing Test(UK TECHNICS)
Vibration Detection Accuracy ± 1%
Inspection Frequency = 100%
3. Bypass Valve Test(Italy REDAT)
Detection Accuracy Test ± 0.5%
Detection Frequency = 100%
4. Overall Performance Test Bench(Test Bench China NJ408)
Now, Contact us for more
professional service and accurate data of our products.
Business Information
Trade Terms: FOB,CIF,EXW
Payment Terms: T/T, Western Union, Paypal, Escrow.
Payment Condition: 30% desposit in advance, 70% balance before delivery
Delivery Time: Within 7 days after the payment
Packing: 1.Neutral Packing Or the package as requirement.
2.One turbo in a Carton.
3.Wooden case is a good choice for ocean shipping.
Shipping: By sea,by air and by express delivery.
After-sale Service:24 Hours around the clock & 12 Months Warranty.
