Product Name:
Turbocharger TD025S2 Turbo Charger For Citroen | Peugeot 49173-07502
Product Attribute:
Engine Model:DV6B
Turbo Model:TD025S2
Engine Power:136kw
Size:OEMcm
G.W:7.5kg
Turbine Material:K18
Power:136kw
Displacement:OEMl
Name:Turbocharger TD025S2 Turbo Charger For Citroen Peugeot 49173-07502
Item name:49173-07502
Cooled Type:Oil cooled
Build/Year:2004
Capacity:2500 ccm
Fuel Type:Diesel
Brand:Tanboress
Warranty:12 Months
Certificate:CE/BV/GMC/TUV/ISO9001
Net Weight:7.5kg
Application:
Citroen Berlingo 1.6L Hdi 75 HP | Citroen Berlingo 1.6L Hdi 90 HP | Citroen C3 1.6L Hdi 90 HP | Citroen C4 1.6L HDi 90 HP | Citroen Jumpy 1.6L HDi 90 HP | Citroen Xsara 1.6L Hdi 90 HP | Citroen Picasso 1.6L Hdi 90 HP | Peugeot 207 1.6L Hdi 90 HP | Peugeot 307 1.6L Hdi 90 HP | Peugeot 308 1.6L HDi FAP 90 HP | Peugeot Expert 1.6L HDi FAP 90 HP | Peugeot Partner 1.6 Hdi 75 HP | Peugeot Partner 1.6 Hdi 90 HP | Fiat Scudo III 1.6 JTD 90 HP | Ford Focus II 1.6L TDCi 90 HP | Ford Fusion 1.6L TDCi 90 HP | Ford Fiesta VI 1.6L TDCi 90 HP | Ford C-MAX 1.6L TDCi 90 HP
Product Description:
Turbocharger TD025S2 Turbo Charger For Citroen | Peugeot 49173-07502
TBS No. |
TBS-0228 |
Related Part No. |
Application For |
OEM No. |
49173-07502 |
49173-07502
49173-07503
49173-07504
49173-07506
49173-07507
49173-07508
49173-56203
49173-07513
49173-07514
49173-07516
49173-07517
49173-07518
49173-07522
49173-07523
49173-07524
49173-07526
49173-07527
49173-07528
4917307502
4917307503
4917307504
4917307506
4917307507
4917307508
4917356203
4917307513
4917307514
4917307516
4917307517
4917307518
4917307522
4917307523
4917307524
4917307526
4917307527
4917307528
1335262
1441254
1479841
1523337
1684949
71793889
71793891
71794229
9657530580
9657603780
9662371080
9670371380
9682881380
9682881780
9685293080
0375J0
0375N0
0375K5
0375N5
0375Q2
0375Q3
0375Q4
0375Q5
3M5Q6K682DA
3M5Q6K682DB
3M5Q6K682DC
3M5Q6K682DD
3M5Q6K682DE
3M5Q-6K682-DA
3M5Q-6K682-DB
3M5Q-6K682-DC
3M5Q-6K682-DD
3M5Q-6K682-DE |
Citroen Berlingo 1.6L Hdi 75 HP | Citroen Berlingo 1.6L Hdi 90 HP | Citroen C3 1.6L Hdi 90 HP | Citroen C4 1.6L HDi 90 HP | Citroen Jumpy 1.6L HDi 90 HP | Citroen Xsara 1.6L Hdi 90 HP | Citroen Picasso 1.6L Hdi 90 HP | Peugeot 207 1.6L Hdi 90 HP | Peugeot 307 1.6L Hdi 90 HP | Peugeot 308 1.6L HDi FAP 90 HP | Peugeot Expert 1.6L HDi FAP 90 HP | Peugeot Partner 1.6 Hdi 75 HP | Peugeot Partner 1.6 Hdi 90 HP | Fiat Scudo III 1.6 JTD 90 HP | Ford Focus II 1.6L TDCi 90 HP | Ford Fusion 1.6L TDCi 90 HP | Ford Fiesta VI 1.6L TDCi 90 HP | Ford C-MAX 1.6L TDCi 90 HP |
Turbo Model |
TD025S2 |
Engine Code |
DV6B |
Cooled Type |
Oil cooled |
Power |
136HP |
Build/Year |
2004 |
Capacity |
2500 ccm |
Fuel Type |
Diesel |
Net Weight |
7kg |
Gross Weight |
7.5kg |
Volume |
|
Brand |
Tanboress |
Warranty |
12 Months |
Certificate |
CE/BV/GMC/TUV/ISO9001 |
Material Description
1. Compressor Housing : ZL 101 Cast aluminum
2. Turbine Housing : D-5S. Scope of heat-resistant950°
3. Bearing Housing : HT250 Gray iron
4. Compressor Wheel : ZL201 or C355 cast aluminums
5. Turbine Wheel : K18. Scope of heat-resistant950°
6. Turbine Shaft : 42CrMo
7. Floating Bearing : CW713R
8. Seal Ring : CrMoNiTi
9. Thrust Bearing : CW713R or ZQSn10-10
Really close to OEM manufacturers quality!
Really the lowest repair rate under the same shelf life!
Really high-temperature resistant, non-deformation for a long time!
Manufacturerprovide you with detailed product material testing report.
Machining Precision Description
High-precision processing equipmentHARDINGE CNC
4-axis linkage machining centerJirfine Taiwan CNC
1. Compressor Housing: Machining precision up to IT6 grades
2. Turbine Housing: Machining precision up to IT6 grades
3. Center Housing: Machining precision up to IT6 grades
4. Compressor Wheel: Accurate run-out, verticality and ovality
5. Turbine Wheel: Overall friction welding technology
The more accurate data belong to our trade secrets.
Should further information be required, please feel free to contact us!
Product Performance Testing Description:
1. The TURBO ROTOR SHAFT & WHEEL Balancing Test(Italy REDAT)
Detection Accuracy = 0.0001g
Test Frequency = 100%
2. The TURBO CARTRIDGE Balancing Test(UK TECHNICS)
Vibration Detection Accuracy ± 1%
Inspection Frequency = 100%
3. Bypass Valve Test(Italy REDAT)
Detection Accuracy Test ± 0.5%
Detection Frequency = 100%
4. Overall Performance Test Bench(Test Bench China NJ408)
Now, Contact us for more
professional service and accurate data of our products.
Business Information
Trade Terms: FOB,CIF,EXW
Payment Terms: T/T, Western Union, Paypal, Escrow.
Payment Condition: 30% desposit in advance, 70% balance before delivery
Delivery Time: Within 7 days after the payment
Packing: 1.Neutral Packing Or the package as requirement.
2.One turbo in a Carton.
3.Wooden case is a good choice for ocean shipping.
Shipping: By sea,by air and by express delivery.
After-sale Service:24 Hours around the clock & 12 Months Warranty.
