Product Name:
Turbocharger BV39 Turbo Charger For Renault 54399880076
Product Attribute:
Engine Model:K9K Euro5 5T
Turbo Model:TD025S2
Engine Power:136kw
Size:OEMcm
G.W:7.5kg
Turbine Material:K18
Power:136kw
Displacement:OEMl
Name:Turbocharger BV39 Turbo Charger For Renault 54399880076
Item name:54399880076
Cooled Type:Oil cooled
Build/Year:2004
Capacity:2500 ccm
Fuel Type:Diesel
Brand:Tanboress
Warranty:12 Months
Certificate:CE/BV/GMC/TUV/ISO9001
Net Weight:7.5kg
Application:
Renault Megane III 1.5 DCI K9K Euro5 5T 106 HP
Product Description:
Turbocharger BV39 Turbo Charger For Renault 54399880076
|
TBS No. |
TBS-2235 |
Related Part No. |
Application For |
|
OEM No. |
54399880076 |
54399880076
54399880087
54399880127
54399700076
54399700087
54399700127
54399980127
5439 988 0076
5439 988 0087
5439 988 0127
5439 970 0076
5439 970 0087
5439 970 0127
5439 998 0127
5439-988-0076
5439-988-0087
5439-988-0127
5439-970-0076
5439-970-0087
5439-970-0127
5439-998-0127
7701479077
8200808701
8200889697
144112505R
144114256R
144116289R
14411-2505R
14411-4256R
14411-6289R |
Renault Megane III 1.5 DCI K9K Euro5 5T 106 HP |
|
Turbo Model |
BV39 |
|
Engine Code |
K9K Euro5 5T |
|
Cooled Type |
Oil cooled |
|
Power |
136HP |
|
Build/Year |
2004 |
|
Capacity |
2500 ccm |
|
Fuel Type |
Diesel |
|
Net Weight |
7kg |
|
Gross Weight |
7.5kg |
|
Volume |
|
|
Brand |
Tanboress |
|
Warranty |
12 Months |
|
Certificate |
CE/BV/GMC/TUV/ISO9001 |
Material Description
1. Compressor Housing : ZL 101 Cast aluminum
2. Turbine Housing : D-5S. Scope of heat-resistant950°
3. Bearing Housing : HT250 Gray iron
4. Compressor Wheel : ZL201 or C355 cast aluminums
5. Turbine Wheel : K18. Scope of heat-resistant950°
6. Turbine Shaft : 42CrMo
7. Floating Bearing : CW713R
8. Seal Ring : CrMoNiTi
9. Thrust Bearing : CW713R or ZQSn10-10
Really close to OEM manufacturers quality!
Really the lowest repair rate under the same shelf life!
Really high-temperature resistant, non-deformation for a long time!
Manufacturerprovide you with detailed product material testing report.
Machining Precision Description
High-precision processing equipmentHARDINGE CNC
4-axis linkage machining centerJirfine Taiwan CNC
1. Compressor Housing: Machining precision up to IT6 grades
2. Turbine Housing: Machining precision up to IT6 grades
3. Center Housing: Machining precision up to IT6 grades
4. Compressor Wheel: Accurate run-out, verticality and ovality
5. Turbine Wheel: Overall friction welding technology
The more accurate data belong to our trade secrets.
Should further information be required, please feel free to contact us!
Product Performance Testing Description:
1. The TURBO ROTOR SHAFT & WHEEL Balancing Test(Italy REDAT)
Detection Accuracy = 0.0001g
Test Frequency = 100%
2. The TURBO CARTRIDGE Balancing Test(UK TECHNICS)
Vibration Detection Accuracy ± 1%
Inspection Frequency = 100%
3. Bypass Valve Test(Italy REDAT)
Detection Accuracy Test ± 0.5%
Detection Frequency = 100%
4. Overall Performance Test Bench(Test Bench China NJ408)
Now, Contact us for more
professional service and accurate data of our products.
